Product Details:
|
| Type: | Vacuum Packing Machine, Modified Atmosphere Pack Machine | Applicable Industries: | Building Material Shops, Construction Works , Food & Beverage Factory, Hotels, Machinery Repair Shops, Manufacturing Plant, Retail |
|---|---|---|---|
| Showroom Location: | Indonesia, Italy, Kazakhstan, Thailand | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Warranty Of Core Components: | 1 Year |
| Core Components: | Bearing, Engine, Gear, Gearbox, Motor, PLC, Pump | Condition: | New |
| Application: | Commodity, Food, Other | Packaging Type: | Belt, Case, Film, Foil |
| Packaging Material: | Metal, Paper | Automatic Grade: | Automatic |
| Driven Type: | Electric | Voltage: | 380/420V |
| Weight: | 516 KG | Warranty: | 1 Year |
| Key Selling Points: | Energy Saving | Product Name: | Skin Pack Machine |
| Packing Speed: | 3-5 Time/min | Vacuum: | Less Than 200Pa |
| Film Material: | Trays, Plastic, Composite Film | Frequency Converter: | Panasonic |
| Machine Material: | Stainless Steel | Film Thickness: | 0.04-0.09mm |
| Compressed Air: | More Than 0.6Mpa | Forming And Drawing Depth: | Less Than 10mm |
Vacuum skin packaging machine is the equipment that uses heat and vacuum to pull the transparent and flexible top skin film tight to the product and seal it to the trays (pre-made or thermoformed). All atmosphere is removed from inside the package.
| Plastic tray dimension | No limitation |
| Tray quantity per cycle | 2/3/4 PCs |
| Vacuum pump | 160/200 m3/h |
| Power supply | Customize voltage, 3 Phase |
| Packing speed (4 trays per cycle) | 400-600 trays/hour |
| Sealing lid film roll width Max. | Customize |
| Sealing lid film roll diameter Max. | 260 mm |
| Compressed air | 0.6-0.8 MPa |
Features
Vaccum Skin Package Benefits
The shelf life is nearly double that of a traditional MAP package, and about four times longer than a stretch-wrapped product.
Food producers can include sauces and soups into packages without having them transfer between food components and purge .
Vacuumskin packaging is neat and compact, with the least printings, marks, and labels.
Bottle rigid trays can support and protect the food products during shipping, storage, and display.
